Pay cash discounted price and save
Pay cash discounted price and save
EMI available for 12 months on regular price: ৳11,550
| Basic Information | ||
| Supported CPU | Support the 14th/13th and 12th generation Intel adapting to the LGA 1700 slot of the motherboard Core TM, Pentium And Cylon processor | |
| Chipset | Intel H610 | |
| Form Factor | M-ATX 245mm x 245mm |
|
| BIOS | 128M UEFI, supporting multiple languages | |
| Audio | 5.1 sound card | |
| Expansion Slots | ||
| PCI | 1xPCIe 4.0 x16 slot 1xPCIe 3.0 x1 slot |
|
| Memory | ||
| Type | DDR4 | |
| Slots | 2 | |
| Supported Memory | - DDR4-3200/2933/2666/2400MHz memory - support dual-channel memory technology |
|
| Maximum Memory | support up to 64 GB of memory (a single slot can support up to 32 GB of memory) | |
| Graphics | ||
| Graphics | Integrated Graphics Processor-Intel HD Graphics support: 1 x HDMI 2.0 interface, Up to 4K 60Hz resolution - 1×VGA interface |
|
| Connector & Ports | ||
| HDMI | 1x HDMI | |
| LAN Port (s) | RTL8111H Gigabit network card | |
| Wireless Communication module | RTL8821CE/AC3165 WiFi 5 Wireless network, Bluetooth 4.2 | |
| Supported Storage | A total of 1 M.2 slot and 4 SATA 6Gb/s hard disk interfaces are supported - M2_ 1 slot: supports 2242/2280 specification M.2 SSD (PCIe 3.0 x4, PCH channel) |
|
| Internal I/O Ports | Rear I/O: - 1×PS/2 interface - 4×USB 2.0 interfaces - 2×USB 3.2 Gen 1 Type-A interfaces - 1×HDMI 2.0 interface, Up to 4K 60Hz resolution - 1×VGA interface - 1×Gigabit network interface - 3×Audio interfaces (audio input/audio output/microphone) On board: - 1×CPU fan pin - 2×System fan pins - 1×water cooling pump pin - 1×USB 2.0 pin can expand 2 USB 2.0 Type-A interfaces - 1×USB 3.2 Gen 1 pin can expand 2 USB 3.2 Gen 1 Type-A interfaces - 1×Front audio pin - 1×Front panel pin - 1×Speaker pin - 1×COM port pin - 1×ME write protection jumper - 1×Clear CMOS jumper - 1×BIOS burner pin - 1×POST Card pin - 1×Wake-up control jumper |
|
| Warranty Details | ||
| Warranty Details | 3 years | |
Get specific details about this product from customers who own it.
