Pay cash discounted price and save
Pay cash discounted price and save
EMI available for 12 months on regular price: ৳21,200
| Basic Information | ||
| Supported CPU | Supports AMD Ryzen 9000/ 8000/ 7000 Series Desktop Processors Socket AM5 |
|
| Chipset | AMD B840 | |
| Form Factor | mATX 243.84mmx243.84mm |
|
| BIOS | Flash BIOS Button | |
| Audio | Realtek ALC897 7.1-Channel High Definition Audio |
|
| Expansion Slots | ||
| PCI | 1x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E1 slot • Supports PCIe 4.0 x16 (For Ryzen™ 9000/ 7000 Series processors) • Supports PCIe 4.0 x8 (For Ryzen™ 8700/ 8600/ 8400 Series processors) • Supports PCIe 4.0 x4 (For Ryzen™ 8500/ 8300 Series processors) |
|
| M.2 Socket | 2x M.2 M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M2_2 slot • Supports up to PCIe 4.0 x4 • Supports up to PCIe 4.0 x2 (For Ryzen™ 8500/ 8300 Series processors) |
|
| Memory | ||
| Type | DDR5 | |
| Slots | 4x UDIMM | |
| Supported Memory | Memory Support DDR5 8000 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s Ryzen 9000 Series Processors max. overclocking frequency: • 1DPC 1R Max speed up to 8000+ MT/s • 1DPC 2R Max speed up to 6400+ MT/s • 2DPC 1R Max speed up to 6400+ MT/s • 2DPC 2R Max speed up to 5600+ MT/s Supports AMD POR Speed and JEDEC Speed Supports Memory Overclocking and AMD EXPO Supports Dual-Channel mode Supports Non-ECC, Un-buffered memory Supports CUDIMM, Clock Driver bypass mode only |
|
| Maximum Memory | 256GB | |
| Graphics | ||
| Graphics | 1x HDMI Support HDMITM 2.1, maximum resolution of 4K 60Hz |
|
| Connector & Ports | ||
| HDMI | 1x HDMI | |
| USB (s) | 4x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 5Gbps Type A (Rear) 2x USB 5Gbps Type A (Front) 1x USB 5Gbps Type C (Front) 1x USB 10Gbps Type A (Rear) 1x USB 10Gbps Type C (Rear) |
|
| LAN Port (s) | Realtek 8125D 2.5G LAN | |
| Wireless Communication module | Wi-Fi 6E The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz (160MHz) up to 2.4Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax Supports Bluetooth 5.3, FIPS, FISMA |
|
| Supported Storage | 2x M.2 M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 4x SATA 6G M2_2 slot • Supports up to PCIe 4.0 x4 • Supports up to PCIe 4.0 x2 (For Ryzen 8500/ 8300 Series processors) |
|
| RAID | Supports RAID 0, RAID 1, and RAID 10 for SATA storage devices Supports RAID 0 and RAID 1 for M.2 NVMe storage devices |
|
| Audio | 1x Front Audio (JAUD) | |
| Internal I/O Ports | 1x Power Connector(ATX_PWR) 1x Power Connector(CPU_PWR) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 3x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 1x Tuning Controller connector(JDASH) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 5Gbps Type A ports 1x USB 5Gbps Type C ports |
|
| TPM (Trusted Platform Module ) | 1x TPM pin header(Support TPM 2.0) | |
| Others | ||
| Special Features | 4x EZ Debug LED 1x EZ Memory Detection LED |
|
| Warranty Details | ||
| Warranty Details | 3 Years of warranty | |
Building a next-gen AMD PC? This motherboard is basically the “serious business” option. Clean design, strong connectivity, PCIe 4.0 support, DDR5 overclocking up to 8000+ MT/s, and built-in WiFi 6E. It’s compact, powerful, and ready for Ryzen 7000, 8000, and 9000 series processors.
Socket: AM5
Chipset: AMD B840
Supported CPUs: AMD Ryzen 9000 / 8000 / 7000 Series Desktop Processors
Flash BIOS Button: Yes (easy BIOS update without CPU hassle)
Perfect for gamers, creators, and workstation users stepping into AMD’s latest platform.
4 x DDR5 UDIMM Slots
Max Capacity: 256GB
Memory Speed:
8000 – 5600 MT/s (OC)
5600 – 4800 MT/s (JEDEC)
Supports AMD EXPO
Dual-Channel Mode
Non-ECC Unbuffered Memory
Supports CUDIMM (Clock Driver bypass mode only)
1DPC 1R: Up to 8000+ MT/s
1DPC 2R: Up to 6400+ MT/s
2DPC 1R: Up to 6400+ MT/s
2DPC 2R: Up to 5600+ MT/s
Translation? This board can handle serious RAM speed if your kit is built for it.
1 x PCIe 4.0 x16 Slot (From CPU)
1 x PCIe 3.0 x1 Slot (From Chipset)
PCIe x16 configuration varies by processor:
Ryzen 9000/7000 → PCIe 4.0 x16
Ryzen 8700/8600/8400 → PCIe 4.0 x8
Ryzen 8500/8300 → PCIe 4.0 x4
Solid support for modern GPUs and high-speed devices.
2 x M.2 PCIe 4.0 x4 Slots (From CPU)
Supports 2280 / 2260 devices
4 x SATA 6G Ports
RAID 0, 1, 10 (SATA)
RAID 0, 1 (M.2 NVMe)
Perfect for high-speed SSD setups or secure storage arrays.
Realtek 8125D 2.5G LAN
WiFi 6E (Pre-installed M.2 Key-E module)
Supports 2.4GHz / 5GHz / 6GHz (160MHz)
Up to 2.4Gbps
Bluetooth 5.3
Stable wired speed + ultra-fast wireless. No excuses for lag.
1 x HDMI 2.1 (4K @ 60Hz)
1 x USB 10Gbps Type-C
1 x USB 10Gbps Type-A
2 x USB 5Gbps Type-A
4 x USB 2.0
2.5G LAN Port
1 x USB 5Gbps Type-C
2 x USB 5Gbps Type-A
4 x USB 2.0
TPM 2.0 Header
3 x Addressable RGB (JARGB_V2)
1 x RGB Header
4 x EZ Debug LED
EZ Memory Detection LED
You’ve got enough headers to light up your whole case like a spaceship.
Form Factor: Micro-ATX
Dimensions: 243.84mm x 243.84mm
Compact but packed with features — perfect for mid-tower or smaller builds.
Flash BIOS Button
4 x EZ Debug LED
EZ Memory Detection LED
TPM 2.0 Support
Troubleshooting made simple, even for first-time builders.
If you want:
AM5 future-proof platform
DDR5 up to 8000+ MT/s
PCIe 4.0 GPU & NVMe support
Built-in WiFi 6E + Bluetooth 5.3
2.5G LAN
256GB max RAM support
This board is a smart investment for high-performance AMD builds without going full premium-tier pricing.
