Pay cash discounted price and save
Pay cash discounted price and save
EMI available for 12 months on regular price: ৳14,700
| Basic Information | ||
| Supported CPU | AMD Socket AM4, support for: AMD Ryzen 5000 G-Series Processors/ AMD Ryzen 5000 Series Processors/ AMD Ryzen 4000 G-Series Processors/ AMD Ryzen 3000 G-Series Processors/ AMD Ryzen 3000 Series Processors |
|
| Chipset | AMD B550 | |
| Form Factor | Micro ATX Form Factor; 24.4cm x 24.4cm |
|
| BIOS | 1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
|
| Audio | Realtek ALC1220 CODEC High Definition Audio 2/4/5.1/7.1-channel |
|
| Expansion Slots | ||
| PCI | 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU: AMD Ryzen 5000/3000 Series Processors support PCIe 4.0 x16 mode AMD Ryzen 5000 G/4000 G/3000 G Series Processors support PCIe 3.0x16 mode * The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot. |
|
| M.2 Socket | 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2280 SSDs: AMD Ryzen 5000/3000 Series Processors support SATA and PCIe 4.0x4/x2 SSDs AMD Ryzen 5000 G/4000 G/3000 G Series Processors support SATA and PCIe 3.0 x4/x2 SSDs 1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 2280 SATA and PCIe 3.0 x2 SSDs |
|
| Others | Chipset: - 1 x PCI Express x16 slot (PCIEX4), supporting PCIe 3.0 and running at x4 - 1 x PCI Express x1 slot (PCIEX1), supporting PCIe 3.0 and running at x1 |
|
| Memory | ||
| Type | Dual Channel DDR4 Memory Technology |
|
| Slots | 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity)of system memory |
|
| Supported Memory | Support for DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C) / 3400(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MT/s memory modules Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules |
|
| Maximum Memory | 128 GB |
|
| Graphics | ||
| Graphics | Integrated Graphics Processor with AMD Radeon Graphics support: - 1 x DisplayPort, supporting a maximum resolution of 5120x2880@60 Hz * Support for DisplayPort 1.4 version, HDCP 2.3, and HDR. - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz |
|
| Connector & Ports | ||
| HDMI | - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz |
|
| USB (s) | CPU: - 4 x USB 3.2 Gen 1 ports on the back panel Chipset: - 1 x USB Type-C port with USB 3.2 Gen 1 support, available through the internal USB header - 2 x USB 3.2 Gen 1 ports available through the internal USB header - 4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through the internal USB header) |
|
| LAN Port (s) | Realtek GbE LAN chip (1 Gbps/100 Gbps/10 Mbps) |
|
| Supported Storage | 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2280 SSDs: AMD Ryzenâ„¢ 5000/3000 Series Processors support SATA and PCIe 4.0x4/x2 SSDs AMD Ryzenâ„¢ 5000 G/4000 G/3000 G Series Processors support SATA and PCIe 3.0 x4/x2 SSDs 1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 2280 SATA and PCIe 3.0 x2 SSDs 4 x SATA 6Gb/s connectors RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices RAID 0, RAID 1, and RAID 10 support for SATA storage devices |
|
| RAID | RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices RAID 0, RAID 1, and RAID 10 support for SATA storage devices |
|
| Audio | Realtek ALC1220 CODEC * The back panel line out jack supports DSD audio. |
|
| Warranty Details | ||
| Warranty Details | 03 years Warranty |
|
Reliable AMD B550 motherboard with high-speed performance and upgrade flexibility
The GIGABYTE B550M DS3H R2 supports AMD Ryzen processors, offering strong performance for gaming and productivity. With PCIe 4.0 support, multiple storage options, and durable build quality, it is ideal for modern PC builds.
The GIGABYTE B550M DS3H R2 mATX AMD Motherboard is designed for users who want a stable and feature-rich platform for their AMD-based systems. Built on the B550 chipset, it supports a wide range of AMD Ryzen processors, making it suitable for gaming, content creation, and everyday computing.
With PCIe 4.0 support, this motherboard ensures faster data transfer speeds for GPUs and NVMe SSDs, enhancing overall system performance. It also supports high-speed memory, allowing smoother multitasking and improved system responsiveness.
The board includes multiple connectivity options such as USB ports, HDMI, and expansion slots, making it versatile for different setups. Its durable components and efficient thermal design ensure long-lasting and stable performance even under heavy workloads.
Whether you're building a gaming PC or upgrading your system, the GIGABYTE B550M DS3H R2 provides reliability, performance, and upgrade flexibility at an affordable price.
Q1: Which processors are supported?
It supports AMD Ryzen processors.
Q2: Does it support PCIe 4.0?
Yes, it includes PCIe 4.0 support for faster data transfer.
Q3: Is it good for gaming?
Yes, it is suitable for entry to mid-range gaming builds.
Q4: What form factor is this motherboard?
It is a micro-ATX (mATX) motherboard.
Q5: Can it be upgraded?
Yes, it supports future upgrades for RAM, storage, and GPU.
Get specific details about this product from customers who own it.
