Pay cash discounted price and save
Pay cash discounted price and save
EMI available for 12 months on regular price: à§³18,550
| Basic Information | ||
| Supported CPU | Support Intel Core Ultra Processors (Series 2), LGA1851 Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0** |
|
| Chipset | Intel H810 | |
| Form Factor | micro-ATX Form Factor 9.6 inch x 8.75 inch (24.4 cm x 22.2 cm) |
|
| BIOS | 256 (128+128) Mb Flash ROM, UEFI AMI BIOS | |
| Audio | Realtek 7.1 Surround Sound High Definition Audio CODEC* - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - Supports up to 24-bit/192 kHz playback Audio Features - Audio Shielding - Premium audio capacitors - Dedicated audio PCB layers * A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output. |
|
| Expansion Slots | ||
| PCI | Intel Core Ultra Processors (Series 2) 1 x PCIe 4.0 x16 slot Intel H810 Chipset 1 x PCIe 4.0 x1 slot |
|
| Memory | ||
| Type | DDR5 | |
| Slots | 2x DIMM | |
| Supported Memory | Supports up to 6400MT/s, Non-ECC, Un-buffered, Clocked Unbuffered DIMM (CUDIMM)* Dual-channel memory architecture DIMM Fit Supports Intel Extreme Memory Profile (XMP) memory module ASUS Enhanced Memory Profile II (AEMP II) * Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration. For more information, please refer to the CPU/Memory Support list under the Support tab of the product information site or visit https://www.asus.com/support/download-center/. Adjustments will be made based on the specifications of mass-produced memory products available on the market. ** Non-ECC, un-buffered DDR5 memory supports On-Die ECC function. |
|
| Maximum Memory | 128GB | |
| Graphics | ||
| Graphics | ** Supports max. 4K@60Hz as specified in DisplayPort 1.4. *** Supports 4K@60Hz as specified in HDMI 2.1. **** VGA resolution support depends on processors' or graphics cards' resolution. |
|
| Connector & Ports | ||
| HDMI | 1 x HDMI port | |
| USB (s) | Rear USB (Total 6 ports) 2 x USB 10Gbps ports (2 x Type-A) 4 x USB 2.0 ports (4 x Type-A) Front USB (Total 5 ports) 1 x USB 5Gbps connector (supports USB Type-C)* 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports 1 x USB 2.0 header supports 2 additional USB 2.0 ports * USB Type-C power delivery output: max. 5V/3A ** USB_E1 port, USB_E2 port, USB_E3 port and USB_E4 port share the bandwidth. |
|
| Wireless Communication module | Wi-Fi 6 1x1 Wi-Fi 6 (802.11ax) Supports 2.4/5GHz frequency band Bluetooth v5.3* |
|
| Supported Storage | Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports Intel H810 Chipset M.2_1 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode) M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x2 mode) 4 x SATA 6Gb/s ports |
|
| Audio | Realtek 7.1 Surround Sound High Definition Audio CODEC* - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - Supports up to 24-bit/192 kHz playback |
|
| Internal I/O Ports | Fan and Cooling Related 1 x 4-pin CPU Fan header 2 x 4-pin Chassis Fan headers Power Related 1 x 24-pin Main Power connector 1 x 8-pin +12V CPU Power connector Storage Related 2 x M.2 slots (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 5Gbps connector (supports USB Type-C) 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports 1 x USB 2.0 header supports 2 additional USB 2.0 ports Miscellaneous 3 x Addressable Gen 2 headers 1 x Clear CMOS header 1 x COM Port header 1 x Front Panel Audio header (F_AUDIO) 1 x S/PDIF Out header 1 x SPI TPM header (14-1 pin) 1 x 10-1 pin Front Panel System header |
|
| Others | ||
| Special Features | ASUS 5X PROTECTION III - DIGI+ VRM - LANGuard - Overvoltage protection - SafeSlot Core+ - Stainless-steel back I/O ASUS Q-Design - Q-DIMM - Q-Dashboard - Q-LED Core - Q-Slot ASUS Thermal Solution - VRM heatsink design Aura Sync - Addressable Gen 2 headers |
|
| Bundled Software | ASUS Exclusive Software Armoury Crate - Aura Sync - Fan Xpert 2+ - Power Saving ASUS DriverHub ASUS GlideX ASUS CPU-Z Norton 360 Deluxe (60 Days Free Trial) WinRAR (40 Days Free Trial) UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash - ASUS UEFI BIOS EZ Mode - ASUS MyHotkey |
|
| Warranty Details | ||
| Warranty Details | 3-Year Brand Warranty (Condition applied) | |
Finding a budget-friendly motherboard that still feels modern and future-ready is one of the biggest challenges for PC builders in Bangladesh. Most entry-level options either cut too many features or fail to support the latest processors—leaving users stuck with outdated performance.
The ASUS H810M AYW GAMING WIFI DDR5 Motherboard changes that equation. It’s designed for users who want a next-generation Intel Core Ultra platform without overspending. With support for DDR5 memory, WiFi 6 connectivity, and PCIe 4.0, this board delivers the essentials that truly matter for everyday performance and entry-level gaming.
Whether you're building your first PC, upgrading to LGA1851, or creating a clean, compact setup, this motherboard provides the right balance between cost and capability.
In this guide, we’ll break down how this board solves real user problems, what makes it a smart choice in Bangladesh, and whether it’s the right fit for your build.
Let’s address the core issue:
You want modern performance—but without paying premium prices.
In Bangladesh, most users struggle with:
Many budget motherboards:
The ASUS H810M AYW GAMING WIFI motherboard solves this by offering next-gen essentials at an accessible price point.
This motherboard focuses on delivering real-world performance where it matters most.
This ensures:
Benefits:
Perfect for:
This allows:
Ensures:
Provides:
Ensures:
Choosing the right motherboard is about smart decision-making—not just specs.
1. Platform Longevity
2. Memory Type
3. Connectivity Needs
4. Storage Flexibility
When buying PC components in Bangladesh, trust is everything.
At Four Star IT, we focus on delivering authentic products with real value.
We understand your needs—and we ensure you get the best performance without unnecessary cost.
Explore a wide range of authentic components at Four Star IT — where performance meets trust.
Get specific details about this product from customers who own it.
